How Engineers Execute Underwater Constructions
My personal research findings
It is a complex process that needs careful planning and exact execution to implement advanced measures to reduce water seepage in a coffer dam. Novel approaches are necessary to guarantee the lifetime and structural soundness of important infrastructure projects, given the difficulties associated with submerged construction. Impressive progress has been made in this area using the concrete seal course technique, which marks a midway point in our underwater project.
An engineering marvel, the clamshell bucket is essential to the excavation stage of the coffer dam construction process. When used in conjunction with an excavator, this adaptable instrument allows for the accurate removal of dirt from the job site, creating the foundation for later stages of building. When preparing the ground for the construction of the concrete seal course, its effectiveness and accuracy are crucial.
After the excavation is finished, the emphasis turns to building a strong foundation that is fastened to the underlying bedrock. To provide a solid foundation for the project, piles are first driven into the bedrock using a vibrating hammer machine. The augur machine then starts to work, clearing the cylinder of hard rock so that reinforcement bars can fit within. By ensuring a solid link between the concrete seal course and the bedrock, this careful preparation raises the coffer dam's overall stability.
After putting in the piles, engineers build the concrete seal course, which is a vital defense against soil erosion and water seepage. High workability specialized cement is used to make pouring easier, and a large block is placed strategically at the foot of the pipe to keep water out while it's being built. Pouring concrete precisely is made possible by the use of a hopper bucket and a long-segmented pipe, which also reduces the possibility of seepage water contamination.
In order to preserve the structural integrity, steps are taken to minimize mixing with seepage water as the concrete seal course takes shape. Throughout the pouring operation, the pipe's outlet end is submerged in concrete to keep water from seeping into the mixture. The project's success depends on creating a strong, waterproof seal, which requires careful attention to detail.
After the concrete seal course is finished, attention turns to installing high-quality reinforced bars for the footing shaft of the bridge Pier. These bars are strategically placed to ensure the structural integrity of the pier by withstanding bridge loads and water pressure. The framework for the bridge Pier is then built, and concrete is poured into the structure to increase its strength.
To allow for drying and strengthening, the structure is left undisturbed for a period of 14–28 days after the concrete is poured. During this period, the coffer dam is dismantled to show the robust Bridge Pier below, which is suddenly rendered superfluous and unsightly. But, care must be taken during this procedure to avoid jeopardizing the integrity of the building.
It is crucial to preserve the concrete seal course's integrity since any structural deterioration could put the project's stability in jeopardy. When dismantling the coffer dam, engineers take care to prevent structural damage by removing it above the level of the concrete seal course. This reduces the risk involved. When excavation is required below this point, engineers use methods such sawing sheet piles to protect the structural integrity.
To sum up, the implementation of the concrete seal course technique has brought about a noteworthy progression in the domain of underwater construction. It has empowered engineers to proficiently address water seepage and guarantee the stability of crucial infrastructure undertakings. Engineers can overcome the difficulties associated with underwater building by using precise planning, inventive problem-solving, and execution, opening the door to the creation of robust and durable infrastructure.
