IP address

IP address

An IP address is a unique address that identifies a device on the internet or a local network. IP stands for "Internet Protocol," which is the set of rules governing the format of data sent via the internet or local network.

An Internet Protocol address (IP address) is a numerical label such as 192.0.2.1 that is connected to a computer network that uses the Internet Protocol for communication. An IP address serves two main functions: network interface identification and location addressing.

• Internet Protocol version 4 (IPv4) defines an IP address as a 32-bit number. However, because of the growth of the Internet and the depletion of available IPv4 addresses, a new version of IP (IPv6), using 128 bits for the IP address, was standardized in 1998. IPv6 deployment has been ongoing since the mid-2000s.IP addresses are written and displayed in human-readable notations, such as 192.0.2.1 in IPv4, and 2001:db8:0:1234:0:567:8:1 in IPv6. The size of the routing prefix of the address is designated in CIDR notation by suffixing the address with the number of significant bits, e.g., 192.0.2.1/24, which is equivalent to the historically used subnet mask 255.255.255.0.

• The IP address space is managed globally by the Internet Assigned Numbers Authority (IANA), and by five regional Internet registries (RIRs) responsible in their designated territories for assignment to local Internet registries, such as Internet service providers (ISPs), and other end users. IPv4 addresses were distributed by IANA to the RIRs in blocks of approximately 16.8 million addresses each, but have been exhausted at the IANA level since 2011. Only one of the RIRs still has a supply for local assignments in Africa. Some IPv4 addresses are reserved for private networks and are not globally unique.
• Network administrators assign an IP address to each device connected to a network. Such assignments may be on a static (fixed or permanent) or dynamic basis, depending on network practices and software features.

IP versions

• Two versions of the Internet Protocol are in common use on the Internet today. The original version of the Internet Protocol that was first deployed in 1983 in the ARPANET, the predecessor of the Internet, is Internet Protocol version 4 (IPv4).
• By the early 1990s, the rapid exhaustion of IPv4 address space available for assignment to Internet service providers and end-user organizations prompted the Internet Engineering Task Force (IETF) to explore new technologies to expand addressing capability on the Internet. The result was a redesign of the Internet Protocol which became eventually known as Internet Protocol Version 6 (IPv6) in 1995. IPv6 technology was in various testing stages until the mid-2000s when commercial production deployment commenced.

• Today, these two versions of the Internet Protocol are in simultaneous use. Among other technical changes, each version defines the format of addresses differently. Because of the historical prevalence of IPv4, the generic term IP address typically still refers to the addresses defined by IPv4. The gap in version sequence between IPv4 and IPv6 resulted from the assignment of version 5 to the experimental Internet Stream Protocol in 1979, which however was never referred to as IPv5.

• Other versions v1 to v9 were defined, but only v4 and v6 ever gained widespread use. v1 and v2 were names for TCP protocols in 1974 and 1977, as there was no separate IP specification at the time. v3 was defined in 1978, and v3.1 is the first version where TCP is separated from IP. v6 is a synthesis of several suggested versions, v6 Simple Internet Protocol, v7 TP/IX: The Next Internet, v8 PIP — The P Internet Protocol, and v9 TUBA — Tcp & Udp with Big Addresses.

Subnetworks

• IP networks may be divided into subnetworks in both IPv4 and IPv6. For this purpose, an IP address is recognized as consisting of two parts: the network prefix in the high-order bits and the remaining bits called the rest field, host identifier, or interface identifier (IPv6), used for host numbering within a network. The subnet mask or CIDR notation determines how the IP address is divided into network and host parts.
• The term subnet mask is only used within IPv4. Both IP versions however use the CIDR concept and notation. In this, the IP address is followed by a slash and the number (in decimal) of bits used for the network part, also called the routing prefix. For example, an IPv4 address and its subnet mask may be 192.0.2.1 and 255.255.255.0, respectively. The CIDR notation for the same IP address and subnet is 192.0.2.1/24, because the first 24 bits of the IP address indicate the network and subnet.

IPv4 addresses

• An IPv4 address has a size of 32 bits, which limits the address space to 4294967296 (232) addresses. Of this number, some addresses are reserved for special purposes such as private networks (~18 million addresses) and multicast addressing (~270 million addresses).
• IPv4 addresses are usually represented in dot-decimal notation, consisting of four decimal numbers, each ranging from 0 to 255, separated by dots, e.g., 192.0.2.1. Each part represents a group of 8 bits (an octet) of the address.[8] In some cases of technical writing,[specify] IPv4 addresses may be presented in various hexadecimal, octal, or binary representations.

Subnetting history

• In the early stages of development of the Internet Protocol, the network number was always the highest order octet (most significant eight bits). Because this method allowed for only 256 networks, it soon proved inadequate as additional networks developed that were independent of the existing networks already designated by a network number. In 1981, the addressing specification was revised with the introduction of classful network architecture.

• Classful network design allowed for a larger number of individual network assignments and fine-grained subnetwork design. The first three bits of the most significant octet of an IP address were defined as the class of the address. Three classes (A, B, and C) were defined for universal unicast addressing. Depending on the class derived, the network identification was based on octet boundary segments of the entire address. Each class used successively additional octets in the network identifier, thus reducing the possible number of hosts in the higher order classes (B and C). The following table gives an overview of this now-obsolete system.

Private addresses

1. Early network design, when global end-to-end connectivity was envisioned for communications with all Internet hosts, intended that IP addresses be globally unique. However, it was found that this was not always necessary as private networks developed and public address space needed to be conserved.
2. Computers not connected to the Internet, such as factory machines that communicate only with each other via TCP/IP, need not have globally unique IP addresses. Today, such private networks are widely used and typically connect to the Internet with network address translation (NAT), when needed.

3.Three non-overlapping ranges of IPv4 addresses for private networks are reserved. These addresses are not routed on the Internet and thus their use need not be coordinated with an IP address registry. Any user may use any of the reserved blocks. Typically, a network administrator will divide a block into subnets; for example, many home routers automatically use a default address range of 192.168.0.0 through 192.168.0.255 (192.168.0.0/24).

IPv6 addresses

• In IPv6, the address size was increased from 32 bits in IPv4 to 128 bits, thus providing up to 2128 (approximately 3.403×1038) addresses. This is deemed sufficient for the foreseeable future.

• The intent of the new design was not to provide just a sufficient quantity of addresses, but also redesign routing in the Internet by allowing more efficient aggregation of subnetwork routing prefixes. This resulted in slower growth of routing tables in routers. The smallest possible individual allocation is a subnet for 264 hosts, which is the square of the size of the entire IPv4 Internet. At these levels, actual address utilization ratios will be small on any IPv6 network segment. The new design also provides the opportunity to separate the addressing infrastructure of a network segment, i.e. the local administration of the segment's available space, from the addressing prefix used to route traffic to and from external networks. IPv6 has facilities that automatically change the routing prefix of entire networks, should the global connectivity or the routing policy change, without requiring internal redesign or manual renumbering.

Private addresses

• Just as IPv4 reserves addresses for private networks, blocks of addresses are set aside in IPv6. In IPv6, these are referred to as unique local addresses (ULAs). The routing prefix fc00::/7 is reserved for this block,[10] which is divided into two /8 blocks with different implied policies. The addresses include a 40-bit pseudorandom number that minimizes the risk of address collisions if sites merge or packets are misrouted.

• Early practices used a different block for this purpose (fec0::), dubbed site-local addresses. However, the definition of what constituted a site remained unclear and the poorly defined addressing policy created ambiguities for routing. This address type was abandoned and must not be used in new systems.
• Addresses starting with fe80::, called link-local addresses, are assigned to interfaces for communication on the attached link. The addresses are automatically generated by the operating system for each network interface. This provides instant and automatic communication between all IPv6 hosts on a link. This feature is used in the lower layers of IPv6 network administration, such as for the Neighbor Discovery Protocol.

IP address assignment

• IP addresses are assigned to a host either dynamically as they join the network, or persistently by configuration of the host hardware or software. Persistent configuration is also known as using a static IP address. In contrast, when a computer's IP address is assigned each time it restarts, this is known as using a dynamic IP address.

• Dynamic IP addresses are assigned by network using Dynamic Host Configuration Protocol (DHCP).[13] DHCP is the most frequently used technology for assigning addresses. It avoids the administrative burden of assigning specific static addresses to each device on a network. It also allows devices to share the limited address space on a network if only some of them are online at a particular time. Typically, dynamic IP configuration is enabled by default in modern desktop operating systems.
• The address assigned with DHCP is associated with a lease and usually has an expiration period. If the lease is not renewed by the host before expiry, the address may be assigned to another device. Some DHCP implementations attempt to reassign the same IP address to a host, based on its MAC address, each time it joins the network. A network administrator may configure DHCP by allocating specific IP addresses based on MAC address.

• DHCP is not the only technology used to assign IP addresses dynamically. Bootstrap Protocol is a similar protoc ol and predecessor to DHCP. Dialup and some broadband networks use dynamic address features of the Point-to-Point Protocol.
• Computers and equipment used for the network infrastructure, such as routers and mail servers, are typically configured with static addressing.

Sticky dynamic IP address

• This section does not cite any sources. Please help improve this section by adding citations to reliable sources. Unsourced material may be challenged and removed. (January 2021) (Learn how and when to remove this template message)
• Sticky is an informal term used to describe a dynamically assigned IP address that seldom changes. IPv4 addresses, for example, are usually assigned with DHCP, and a DHCP service can use rules that maximize the chance of assigning the same address each time a client asks for an assignment. In IPv6, a prefix delegation can be handled similarly, to make changes as rare as feasible. In a typical home or small-office setup, a single router is the only device visible to an Internet service provider (ISP), and the ISP may try to provide a configuration that is as stable as feasible, i.e. sticky. On the local network of the home or business, a local DHCP server may be designed to provide sticky IPv4 configurations, and the ISP may provide a sticky IPv6 prefix delegation, giving clients the option to use sticky IPv6 addresses. Sticky should not be confused with static; sticky configurations have no guarantee of stability, while static configurations are used indefinitely and only changed deliberately.

Public address

• A public IP address is a globally routable unicast IP address, meaning that the address is not an address reserved for use in private networks, such as those reserved by RFC 1918, or the various IPv6 address formats of local scope or site-local scope, for example for link-local addressing. Public IP addresses may be used for communication between hosts on the global Internet. In a home situation, a public IP address is the IP address assigned to the home's network by the ISP. In this case, it is also locally visible by logging into the router configuration.
• Most public IP addresses change, and relatively often. Any type of IP address that changes is called a dynamic IP address. In home networks, the ISP usually assigns a dynamic IP. If an ISP gave a home network an unchanging address, it's more likely to be abused by customers who host websites from home, or by hackers who can try the same IP address over and over until they breach a network.

Firewalling

• This section does not cite any sources. Please help improve this section by adding citations to reliable sources. Unsourced material may be challenged and removed. (January 2021) (Learn how and when to remove this template message)
• For security and privacy considerations, network administrators often desire to restrict public Internet traffic within their private networks. The source and destination IP addresses contained in the headers of each IP packet are a convenient means to discriminate traffic by IP address blocking or by selectively tailoring responses to external requests to internal servers. This is achieved with firewall software running on the network's gateway router. A database of IP addresses of restricted and permissible traffic may be maintained in blacklists and whitelists, respectively.
