Aircraft Fuel System Components: A Technical Reference for Procurement and MRO Professionals

The aircraft fuel system is responsible for storing, conditioning, measuring, and delivering fuel to the engines under all flight attitudes, pressure conditions, and temperature environments. It is one of the most tightly regulated systems on any certified aircraft, with every component subject to strict material, contamination, and flammability standards under FAA Part 25 and equivalent international regulations. The global aircraft fuel systems market is led by Parker Hannifin Corporation, Eaton Corporation, RTX (Collins Aerospace), Safran, and Woodward Inc., each supplying overlapping but distinct portions of the system across commercial, business, and military programs. This reference covers each major component category, its function, and the key suppliers active in each segment.

Fuel Storage: Tanks, Bladders, and Structural Wet Bays

Commercial transport aircraft store fuel in structural wing tanks, center tanks, and on some long-range aircraft, trim tanks in the horizontal stabilizer. These are wet bay designs, where the interior of machined aluminum or composite wing structure is sealed to form the fuel boundary rather than using a separate bladder or liner. Business jets and many military aircraft use either wet bays or flexible rubber bladder tanks depending on the airframe design. Tank sealants, fastener seals, and access panel gaskets are life-limited consumables replaced during scheduled structural inspections, with sealant compounds approved and supplied by companies including PPG Aerospace under their PRC brand.

Fuel Boost Pumps and Transfer Pumps

Submerged centrifugal boost pumps located inside each tank maintain positive fuel pressure at the engine-driven high-pressure pump inlet throughout all flight phases, preventing vapour lock at high altitude. Eaton Corporation's Aerospace division is a primary supplier of fuel boost pumps across Boeing 737, 747, 757, and 767 programs, as well as Airbus A320-family and A330 aircraft. Parker Hannifin, following its 2022 acquisition of Meggitt, now supplies boost pump assemblies previously produced under the Meggitt brand, expanding its fuel systems footprint across both commercial and military programs. Transfer pumps move fuel between tanks during flight to maintain centre of gravity within approved limits, with the fuel management system commanding individual pump operation automatically based on tank quantity signals.

Fuel Control Valves and Crossfeed Valves

Motor-operated valves control fuel flow paths between tanks, engines, and refuelling connections. Crossfeed valves allow either engine to draw fuel from tanks on the opposite side of the aircraft in the event of a single-engine fuel feed failure. Shutoff valves in the engine feed lines enable fuel isolation during emergency procedures or fire events. Woodward Inc., which completed its 2026 acquisition of Valve Research and Manufacturing, supplies high-precision flow control valves used across multiple aerospace fuel system applications, strengthening Woodward's position as a specialist in proprietary fuel metering and control components. Parker Hannifin and Eaton each manufacture broad ranges of solenoid and motor-driven fuel valves certified across current narrowbody and widebody programs.

Fuel Quantity Measurement and Level Sensing

Accurate fuel quantity indication is a flight-critical function across all certified aircraft. Capacitance probes installed at multiple heights within each tank measure the dielectric constant of the fuel-air interface to calculate tank contents in pounds or kilograms, compensating automatically for changes in fuel temperature and density. TransDigm Group, through its 2025 acquisition of Simmonds Precision Products from RTX Corporation, now supplies fuel quantity sensing and proximity sensing solutions across a broad range of commercial and military platforms. Simmonds specializes in fuel quantity indication systems that integrate level sensing with the aircraft's Fuel Level Sensing Control Unit (FLSCU), a computer that provides precise real-time tank quantity data to the flight deck and fuel management system simultaneously.

Onboard Inert Gas Generation Systems (OBIGGS)

OBIGGS technology reduces the oxygen concentration inside fuel tank ullage spaces by supplying nitrogen-enriched air generated from filtered engine bleed or compressor air. By displacing oxygen in the ullage, OBIGGS substantially reduces the risk of fuel vapour ignition in the event of a lightning strike or fuel system fault. Following the investigation into the TWA Flight 800 accident, the FAA mandated flammability reduction measures across commercial transport aircraft, making OBIGGS a regulatory requirement for new type designs and a retrofit program across many in-service fleets. Collins Aerospace is a leading supplier of fuel tank inerting systems, producing air separation module assemblies that filter bleed air through hollow fibre membranes to produce nitrogen-enriched air at the purity levels required for tank inerting.

Fuel System Digital Diagnostics and Maintenance Practices

Modern fuel management computers log tank quantity data, pump run times, valve cycle counts, and system fault codes throughout each flight. During scheduled maintenance or when a fuel system advisory is generated on the centralized fault display, technicians connect a laptop to the aircraft's maintenance access terminal to retrieve stored fault data, cross-reference codes against the Fault Isolation Manual, and verify valve position feedback signals before initiating physical troubleshooting. Safran's integrated fuel system solutions for Airbus programs include built-in diagnostics accessible through the aircraft's centralised maintenance system, allowing ground crews to isolate component-level faults efficiently without disassembling the system first.

Sourcing, Traceability, and Shelf Life Management

Fuel system components must be sourced with full airworthiness release documentation and, for elastomeric seals, bladders, and sealants, must be tracked against shelf life and cure date limits that can be as short as five years from manufacture. Operators sourcing boost pumps, valves, or quantity probes from the aftermarket must verify that part number revision levels match the aircraft's approved configuration and that no active airworthiness directives require specific hardware modifications. The 2025 acquisition of Simmonds Precision by TransDigm and Woodward's 2026 acquisition of Valve Research and Manufacturing reflect a broader consolidation trend in the fuel systems supply chain, with OEMs and Tier 1 suppliers acquiring component specialists to expand proprietary aftermarket revenue and secure capacity for growing commercial fleet deliveries.
