In-depth product introduction-1w high-power LoRa Mesh Module E52 Series
LoRa Mesh Module

I recently worked on a wireless sensor network project covering a 3-square-kilometer industrial park, requiring long-distance transmission, multi-node networking, and high reliability. After comparing several solutions, I chose the EBYTE E52-400NW30S and E52-900NW30S as the core networking modules. The experience has been great, so I'm sharing it here.
What exactly are these modules?
These are EBYTE's 1W high-power LoRa MESH networking modules, with a transmit power of up to 30dBm (1W) and decentralized MESH technology. The only difference is the operating frequency band:
E52-400NW30S — 410~509MHz (default 433.125MHz), for China and European markets
E52-900NW30S — 850~929MHz (default 868.125MHz), for North America and Asia-Pacific markets
Five Key Highlights:
1W High Power: Ideal open-area communication distance of up to 4km (air data rate 7Kbps). Strong signal penetration, significantly better coverage in complex environments than standard 22dBm modules.
Decentralized MESH Networking: No central node required. Every device can act as a router. If any node goes offline, the rest of the network is unaffected — extremely high reliability.
Self-Healing Network: When a link is interrupted, routing nodes automatically rediscover paths, ensuring no data loss.
Multi-hop Routing: Data can hop through multiple relay nodes, easily covering large areas or complex terrain.
Four Communication Modes: Supports Unicast, Multicast, Broadcast, and Anycast, flexibly adapting to different application logic.
Key difference from the 22S version: The 30S has 8dBm higher transmit power (about 2.5x the power), with roughly 1.5km more range, but is larger (40.5×25mm) and consumes more power (710mA transmit current), making it better suited as a backbone relay node. In practice, you can mix 30S and 22S modules in the same network to balance range and cost.
This module has been running stably in my project for a month now. Highly recommended for anyone working on long-distance wireless networking.
When choosing between the E52-400NW30S and E52-900NW30S, aside from the frequency band, almost all technical parameters are identical. Here's a detailed comparison table based on the datasheet:
Core Parameter E52-400NW30S E52-900NW30S
Frequency Band 410.125~509.125 MHz 850.125~929.125 MHz
Default Frequency 433.125 MHz 868.125 MHz
Transmit Power 30dBm (1W), user adjustable 30dBm (1W), user adjustable
Air Data Rate 7K / 21.875K / 62.5K bps (3 levels) Same
Receive Sensitivity -121dBm @7K -121dBm @7K
Reference Range 4.0 km (open area, 7K, 3.5dBi antenna) 4.0 km (open area, 7K, 3.5dBi antenna)
Operating Voltage 3.3~5.5V (≥5.0V for full power) 3.3~5.5V (≥5.0V for full power)
Transmit Current 710 mA (instantaneous) 710 mA (instantaneous)
Receive Current ~14 mA ~14 mA
Interface UART (3.3V TTL) UART (3.3V TTL)
Max Baud Rate 460800 bps 460800 bps
Single Packet Size 200 Bytes 200 Bytes
Antenna Interface IPEX / Stamp Hole (50Ω) IPEX / Stamp Hole (50Ω)
Dimensions 40.5 × 25.0 mm 40.5 × 25.0 mm
Operating Temp -40℃ ~ +85℃ (industrial) -40℃ ~ +85℃ (industrial)
Selection Guide:
China & European markets: Choose the E52-400NW30S (433MHz band). This band has better diffraction capability, ideal for environments with many obstacles.
North America & Asia-Pacific markets: Choose the E52-900NW30S (868/915MHz band), compliant with local ISM band regulations.
Parameter tuning: For maximum range, set the air data rate to 7Kbps and lower the baud rate. For higher throughput, set the rate to 62.5Kbps, but range will drop to approximately 1.6km.
Article 3: E52-400/900NW30S Frequently Asked Questions (FAQ)
Section: Technical Support / Q&A
While using the EBYTE E52-400NW30S and E52-900NW30S modules, engineers often run into the same issues. I've compiled this FAQ based on the datasheet and my own experience — hope it helps!
Q1: Actual transmission distance is far less than 4km. What can I do?
A: The 4km figure is an ideal value measured in clear open areas with 7Kbps air rate, 3.5dBi antenna gain, and 2.5m antenna height. In real-world use, these factors reduce range:
Obstacles: Walls, trees, and metal objects significantly attenuate the signal.
Air data rate: 7Kbps → 21.875Kbps can drop range to ~2km; 62.5Kbps may yield only ~1.6km.
Supply voltage: Make sure voltage is ≥5.0V, otherwise transmit power drops.
Antenna quality: Use an antenna with 3.5dBi gain or higher, and keep it away from metal objects.
Q2: The module gets very hot. Is this normal?
A: Yes, this is normal. The transmit current is up to 710 mA, so temperature rise during continuous transmission is expected. Recommendations: ① Leave space around the module for heat dissipation; ② Avoid long periods of continuous full-power transmission; ③ Reserve copper pour or thermal vias on the PCB design.
Q3: How do I avoid damaging the module?
A: ① Power supply: Voltage must not exceed 5.5V, otherwise the module may be destroyed. ② ESD protection: Wear an anti-static wrist strap when handling. ③ Never leave the antenna port open during transmission — an antenna must be connected, otherwise the power amplifier can be damaged by excessive standing wave ratio (SWR).
Q4: How do I check the module's current parameters?
A: Send the AT command AT+INFO=? via serial port. The module will return complete information including model, firmware version, transmit power, operating frequency, PANID, air data rate, and more. This is a powerful diagnostic tool.
Q5: The routing table is empty. What's wrong?
A: The routing table is only populated after data exchange occurs in the network. If the module was just powered on or there's no network traffic, an empty routing table is normal. Let multiple modules exchange data first, then read the routing table again.
Q6: How do I configure a module remotely?
A: When sending remote configuration commands, the target port must be set to Port 14 (other ports don't support remote configuration). Refer to Chapter 7 of the user manual for specific command formats.
Q7: The module won't enter configuration mode. What should I do?
A: Pull the M0 pin low, then power on the module — it should enter configuration mode. If it still doesn't work, check the M0 pin voltage level and verify the serial connection is correct
